Bring Rich Colors to the Night
Unique & Unrivaled Tech Behind Acme Color Night Vision
Experience unparalleled 3K QHD color night vision with NightChroma™ NC500. Featuring an f/1.0 super aperture, advanced backside illumination sensor, high-performance ISP, and precise micro-size alignment, it ensures brighter, clearer, and high-fidelity images. Soft supplement light ensures optimal vision in 0 lux conditions.
Human & Vehicle Detection, Brings 99% Accurate Alerts
Using an intelligent algorithm based on a deep learning platform, the motion detection 2.0 camera will detect people and vehicle, which helps reduce 99% unwanted motion alerts triggered by animals, or random inanimate objects.
Vivid Sound Record, Not Silent Footage
The built-in noise-cancelling microphone filters ambient noise and captures voices up to 20 ft away, enhancing security with vivid audio recordings. Easily mute the audio feature if the audio surveillance is not allowed or you don’t want audio record.
Industry-Leading H.265+ Video Format
H.265+ video compression tech consumes less bandwidth & storage space than H.264, without losing 3K QHD quality. Quadruple H.265+/H.265/H.264+/H.264 video format allows for maximum encryptions and backward compatibility with legacy platforms.
Built to Brave Extreme Hot & Cold Climates
Rated as IP67, this weatherproof camera can withstand pretty much anything, regardless heavy snowfall, torrential downpours. This camera has been tested in extreme temperatures (-22 °F to 140 °F), ensuring all-year-round protection wherever you live.
Made from the same heavy-duty aluminum used in the construction of airplanes, the camera housing can withstand large impacts and is highly resistant to corrosion.
Metal
Rugged Housing
140 °F | 60 °C
Hot Rating
-22 °F | -30 °C
Cold Rating
IP67
Water Rating
Small on Prices, Big on Features
Local Storage
Supports up to 256 GB TF card (not included) for local video storage without monthly cloud fees.
Image Enhancement
20 dB true WDR, 3D DNR, BLC & HLC – to provide the splendid 3K Super HD clarity.
Unlimited Remote Access
Easily access your system via intuitive ANNKE Vision App from virtually anywhere in the world.
PoE or DC Power
Power on the camera via PoE or plug the camera to an outlet for power supply.
What's in the Box
Camera
| Image Sensor1/3" Progressive Scan CMOS | Video Bitrate32 Kbps - 8 Mbps |
|
Main Stream50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720)
60 Hz: 20 fps (3072*1728), 24 fps ( 1920 X 1080, 1280 X 720) |
Substream50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360)
60 Hz: 24 fps (1280 X 720,640 X 480, 640 X 360) |
| Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC | Audio InputBuilt-in Microphone, record with audio |
| Lens2.8 mm@F1.0 | Day & Night24/7 color imaging |
| Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light | Angle of ViewHorizontal FOV: 96°, vertical FOV: 52°, diagonal FOV: 113° |
| Max resolution3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
Video CompressionMain stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG |
| Supplement Light TypeWhite Light | Supplement Light RangeUp to 30 m |
| Motion detection 2.0Supoort, include Human & Vehicle detection | Image EnhancementBLC, HLC, 3D DNR |
| ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | APIOpen Network Video Interface(Profile S, Profile T, Profile G), ISAPI |
| Wide Dynamic Range120 dB WDR | Region of Interest (ROI)1 fixed region for main stream |
| Privacy Mask4 programmable polygon privacy masks | General FunctionRotate mode, mirror, password protection, remote access |
| Image Sensor1/3" Progressive Scan CMOS |
|
Main Stream50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720)
60 Hz: 20 fps (3072*1728), 24 fps ( 1920 X 1080, 1280 X 720) |
| Audio CompressionG.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Lens2.8 mm@F1.0 |
| Min. IlluminationColor: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with light |
| Max resolution3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display |
| Supplement Light TypeWhite Light |
| Motion detection 2.0Supoort, include Human & Vehicle detection |
| ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| Wide Dynamic Range120 dB WDR |
| Privacy Mask4 programmable polygon privacy masks |
| Video Bitrate 32 Kbps - 8 Mbps |
|
Substream 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360)
60 Hz: 24 fps (1280 X 720,640 X 480, 640 X 360) |
| Audio Input Built-in Microphone, record with audio |
| Day & Night 24/7 color imaging |
| Angle of View Horizontal FOV: 96°, vertical FOV: 52°, diagonal FOV: 113° |
|
Video Compression Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG |
| Supplement Light Range Up to 30 m |
| Image Enhancement BLC, HLC, 3D DNR |
| API Open Network Video Interface(Profile S, Profile T, Profile G), ISAPI |
| Region of Interest (ROI) 1 fixed region for main stream |
| General Function Rotate mode, mirror, password protection, remote access |
General
| Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port | HousingMetal & Plastic |
| ColorWhite | Hardware ResetYes |
| StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB | Operating PowerDC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W |
| Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C | Indoor/Outdoor UseIndoor/Outdoor |
| Interface ProtectionIP67 | Dimension (L X W X H)Ø109.9 mm × 103.6 mm (Ø4.3" × 4.1")-I81HE/ Ø 76.6 mm × 164.4 mm (Ø 3" × 6.5")-I81HD |
| WeightApprox. 420 g (0.9 lb.)-I81HE / Approx. 430 g (0.9 lb.)-I81HD |
| Ethernet1 RJ45 10 M/100 M self-adaptive Ethernet port |
| ColorWhite |
| StorageBuilt-in microSD/SDHC/SDXC Slot, up to 256 GB |
| Operating Temperature-22 °F – 140 °F/-30 °C – 60 °C |
| Interface ProtectionIP67 |
| Housing Metal & Plastic |
| Hardware Reset Yes |
| Operating Power DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W |
| Indoor/Outdoor Use Indoor/Outdoor |
| Dimension (L X W X H) Ø109.9 mm × 103.6 mm (Ø4.3" × 4.1")-I81HE/ Ø 76.6 mm × 164.4 mm (Ø 3" × 6.5")-I81HD |
| WeightApprox. 420 g (0.9 lb.)-I81HE / Approx. 430 g (0.9 lb.)-I81HD |
