ANNKE FDH600
Dual-Lens & Full Color
Making Vision Wider, World More Colorful
Dual-lens Fusion Splicing 180°
Ultra-wide Viewing Angle
The dual-lens camera can intelligently splicing images into a 180-degree video image without dead ends, and maintains the aspect ratio of 20:9. Image fusion technology keeps the brightness and color matching of images highly consistent, showing a perfect spliced image.
6MP BSI Sensor with Full-Color Night Vision
Featuring dual 1/2.5" BSI sensors, our camera delivers ultra-clear 3632×1632 resolution, capturing fine details like distant license plates. Switch between IR fill light for black and white images and white light for full-color night vision, all adjustable via your browser settings.
Smart Detection Motion 2.0, Brings 99% Accurate Alerts
Using an intelligent algorithm based on a deep learning platform, the camera not only supports human and vehicle detection, but also supports line crossing detection, intrusion detection, region entrance detection, region exiting detection.
Pre-Active Defense with Siren Deterrence
When a potential intruder, human or vehicle is detected, the built-in horn supports alarm sound output, triggering the alarm to scare the intruder away. There are 12 kinds of alarm sounds to choose from, you can also record your own sound as an alarm sound. The volume of the alarm sound can be adjusted, and the maximum volume is 95dB. External alarm, audio input and output devices can be connected.
Listen & Speak from Any Location
The noise-canceling microphone filters ambient noise and captures voices up to 20 ft away, ensuring HiFi audio. 2-way audio enhances security, letting you communicate with delivery personnel or greet guests. Say “Hi” to your guests – a camera that can see, hear & talk.
Multiple Storage Methods
Built-in TF card slot, supports up to 256GB Micro SD card, supports NAS, NVR storage(Compatible with ANNKE latest version NVR: N48PBB-V2, N44PAM, N48PAW-V2, N46PCK-V2, N931BB, N88PCH, N96PBD, please contact us to help you confirm if your NVR is the latest version before you purchase this camera).
Built to be Prominent in the Harshest Climates
IP66 rated, the powerful weatherproof camera, is designed to work for extreme indoor & outdoor use from -22 °F/-30 °C to 140 °F/60 °C. Whatever the scorching weather or the freezing climates, the camera still works perfectly to produce perfect 6MP videos without the degraded resolution. Made from the heavy-duty ABS, the camera housing can withstand large impacts and is highly resistant to corrosion. Provide you with long-lasting and durable protection.
ABS
Rugged Housing
140 °F | 60 °C
Hot Rating
-22 °F | -30 °C
Cold Rating
IP66
Water Rating
Small on Prices, Big on Features
Advanced H.265 coding
H.265 coding helps the camera record longer videos and consumes less bandwidth.
120dB WDR & 3D DNR
Allow the PoE camera to capture clear footage and images without noise at night.
PoE & DC 12V Power Supply
Power on the camera via PoE with an NVR/PoE injector, or plug it into an outlet for the power supply.
APP Control
View current and past situations anytime and anywhere, and support multi-device remote access.
What's in the Box
Compatible with ANNKE latest version NVR: N48PBB-V2, N44PAM, N48PAW-V2, N46PCK-V2, N931BB, N88PCH, N96PBD.
Please confirm if your NVR is the latest version before you purchase this camera
Please confirm if your NVR is the latest version before you purchase this camera
Camera
| Image sensor2×1/2.5" Progressive Scan CMOS |
Main Stream50 Hz: 20 fps (3632 × 1632)
60 Hz: 20 fps (3632 × 1632) |
|
Sub Stream50 Hz：20 fps（1200 × 536，960 × 432）
60 Hz：20 fps（1200 × 536，960 × 432 |
Video compressionMain Stream: H.265/H.264
Sub Stream: H.265/H.264/MJPEG |
| Video Bit Rate32 Kbps to 16 Mbps | Built-in MicrophoneYes, support environment noise filtering |
| Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 | Built-in SpeakerYes, max. sound pressure: 10 cm: 95 dB |
| LensDual lens: 2.8 mm | Min. IlluminationColor: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR) |
| Angle of ViewHorizontal FOV: 180° ± 10°, Vertical FOV: 81° ± 10° | Supplement Light RangeWhite light up to 20 m, IR light up to 30m |
| Image Parameters SwitchYes | Image EnhancementBLC, HLC, 3D DNR |
| Wide Dynamic Range120dB WDR | Network ProtocolsTCP/IP,ICMP,HTTP,HTTPS,802.1x,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,IGMP,QoS,IPv6,UDP,Bonjour,SSL/TLS,WebSocket,Onvif |
| Basic EventMotion detection (support human and vehicle detection), video tampering | Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection(support human and vehicle detection) |
| Audio AlarmSupport(Parameters adjustable,support custom audio, can be triggered from APP) |
| Image sensor2×1/2.5" Progressive Scan CMOS |
|
Sub Stream50 Hz：20 fps（1200 × 536，960 × 432）
60 Hz：20 fps（1200 × 536，960 × 432 |
| Video Bit Rate32 Kbps to 16 Mbps |
| Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| LensDual lens: 2.8 mm |
| Angle of ViewHorizontal FOV: 180° ± 10°, Vertical FOV: 81° ± 10° |
| Image Parameters SwitchYes |
| Wide Dynamic Range120dB WDR |
| Basic EventMotion detection (support human and vehicle detection), video tampering |
| Audio AlarmSupport(Parameters adjustable,support custom audio, can be triggered from APP) |
|
Main Stream 50 Hz: 20 fps (3632 × 1632)
60 Hz: 20 fps (3632 × 1632) |
|
Video compression Main Stream: H.265/H.264
Sub Stream: H.265/H.264/MJPEG |
| Built-in Microphone Yes, support environment noise filtering |
| Built-in Speaker Yes, max. sound pressure: 10 cm: 95 dB |
| Min. Illumination Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR) |
| Supplement Light Range White light up to 20 m, IR light up to 30m |
| Image Enhancement BLC, HLC, 3D DNR |
| Network Protocols TCP/IP,ICMP,HTTP,HTTPS,802.1x,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,IGMP,QoS,IPv6,UDP,Bonjour,SSL/TLS,WebSocket,Onvif |
| Smart Event Line crossing detection, intrusion detection, region entrance detection, region exiting detection(support human and vehicle detection) |
General
| HousingMetal&Plastic, White color | Operating PowerPoE (802.3af)，12 VDC ± 25%,Ø 5.5 mm coaxial power plug |
| Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port | StorageBuilt-in micro SD/SDHC/SDXC slot, up to 256 GB, support NAS, NVR |
| DC12V outputDC12 V，100 mA output | Audio input/output1 input (line in),1 output (line out) |
| Alarm nput/output1 input, 1 output (max. 24 VDC, 1 A) | Hardware ResetYes |
| Operating Temperature-22 °F – 140 °F /-30°C – 60 °Ct | WeightApprox. 600 g (1.32 lb.) |
| Weatherproof RatingIP66 | Indoor/OutdoorIndoor/Outdoor |
| Dimension (L x W x H)138.1 × 101.1 × 120.4 mm |
| HousingMetal&Plastic, White color |
| Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port |
| DC12V outputDC12 V，100 mA output |
| Alarm nput/output1 input, 1 output (max. 24 VDC, 1 A) |
| Operating Temperature-22 °F – 140 °F /-30°C – 60 °Ct |
| Weatherproof RatingIP66 |
| Dimension (L x W x H)138.1 × 101.1 × 120.4 mm |
| Operating Power PoE (802.3af)，12 VDC ± 25%,Ø 5.5 mm coaxial power plug |
| Storage Built-in micro SD/SDHC/SDXC slot, up to 256 GB, support NAS, NVR |
| Audio input/output 1 input (line in),1 output (line out) |
| Hardware Reset Yes |
| Weight Approx. 600 g (1.32 lb.) |
| Indoor/Outdoor Indoor/Outdoor |
