Up to 32MP 4K Ultra HD Stream
This powerful network video recorder can connect up to 8 pcs PoE IP cameras. Please note that you can only connect 1-channel 32MP camera (30 fps recording rate) to the NVR after you have enabled Ultra HD resolution mode.
Work with All PoE IP Camera
This NVR works with all ANNKE PoE security cameras and third-party IP cameras, from 720p all the way to 32MP 4K resolution.
The NVR doesn’t come with the PoE ports
Please connect the NVR to the router, and then connect your cameras to the same router for 24/7 recording.
Powerful & Versatile Compatibility
This NVR, as the central hub of a security camera system, supports different special functions, including fisheye, people counting, ANPR (automatic number plate recognition). Your camera should support one of these functions, if you want to integrate the functions with your NVR.
Quintuple Video Format
The latest H.265+ video format consumes less storage space & bandwidth without losing the 4K Ultra HD clarity. Quintuple H.265+/H.265/H.264+/H.264/MPEG-4 video format allows for maximum encryptions and backward compatibility with legacy platforms.
Remote Access & Motion Alerts
Access the hybrid network video recorder via free ANNKE Vision App remotely for live stream, video playback & remote setup. When there are motion events, you will receive instant app push notifications and email alerts. You’ll never miss any important moment.
Specification
| Model Number | N981BB | |
| NVR | ||
| Video & Audio | Video Compression | H.264+/H.264/H.265/H.265+/MPEG4 |
| IP Video Input | 8-ch | |
| Video Output | HDMI up to 4K, VGA up to 1080P | |
| Audio Input/Output | 1/1 RCA | |
| Incoming Bandwidth | 80 M | |
| Max Recording Resolution | Up to 12 MP resolution, 32 MP and 24 MP is only available for channel 1 | |
| Max Playback Resolution | Up to 32MP | |
| Max Playback Channel | 8-CH | |
| Max Playback Capacity | 1-ch@32 MP (30 fps)/2-ch@12 MP (20 fps)/4-ch@8 MP (25 fps)/8-ch@4 MP (30 fps)/16-ch@1080p (30 fps) |
|
| ONVIF Protocols | Support | |
| Hard Drive | HDD | 2 SATA Interface |
| HDD Capacity | Up to 10 TB Capacity for Each HDD | |
|
External Interface |
Network Interface | 1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Alarm Input/Output | 4/1 | |
| USB | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 | |
| General | Operating Power | 12 VDC, 3.33 A |
| Power Consumption | ≤ 15 W | |
| Working Temperature | 14 °F ~ 131 °F/-10 °C ~+55 °C | |
| Dimensions (W X H X D) | 385 × 315× 52 mm (15.2" × 12.4" × 2.0") | |
| Weight (Without Hard Disk) | ≤ 1 kg (2.2 lb) | |
| Packaging Contents | ||
| NVR | 1 | |
| USB Mouse | 1 | |
| Power Adapter | 1 | |
| 1M network cable | 1 | |
| 1.8M HDMI cable | 1 | |
| User's Manual For NVR | 1 | |
